Flood Mapping

Part B — HAND, and Lab 7 on the Provo River

CE 414 Engineering Applications of GIS
Civil & Construction Engineering
Brigham Young University
Dr. Dan Ames

CE 414 · Week 8 — Flood Mapping, Part BLast Updated: 2026-10-10© 2026 Daniel P. Ames · CC BY 4.0

Today's Goals

By the end of class you should be able to:

  • Say what HAND measures, and why it beats elevation for floods
  • Build it from a DEM: Lab 5's chain + Flow Distance
  • Turn a flood depth into a flood map with one threshold
  • Score a flood map against another: hit rate, false alarms, CSI
  • Say what Lab 7 asks for, and how you will know you are right
CE 414 · Week 8 — Flood Mapping, Part B

Part 1 — Height Above What?

CE 414 · Week 8 — Flood Mapping, Part B

Elevation Is Measured From the Wrong Place

  • A flood cares how high you are above the river, not above sea level
  • HAND: Height Above Nearest Drainage — the drop from a cell to the stream cell it drains to
  • Every river cell has HAND = 0
CE 414 · Week 8 — Flood Mapping, Part B

HAND on the Provo River

  • Left: elevation, 1,367 to 1,646 m: a ramp toward the mountains
  • Right: HAND, 0 to 198 m: the floodplain shows up as a ribbon along the river
  • About 11% of the cells are within 2 m of the river
CE 414 · Week 8 — Flood Mapping, Part B

How It Is Computed

center

  • Fill → Flow Direction → Flow Accumulation → streams: Lab 5, unchanged
  • Flow Distance, distance type Vertical: HAND, down the path the water takes
CE 414 · Week 8 — Flood Mapping, Part B

The Stream Is the Big Choice

  • HAND is measured to whatever you call a stream
  • Every gully a stream → the 1% flood covers 47.9 km²
  • Only the Provo River (a 30 m corridor) → 1.57 km²
  • Same terrain, same depth: the definition did that
CE 414 · Week 8 — Flood Mapping, Part B

Part 2 — From a Depth to a Flood

CE 414 · Week 8 — Flood Mapping, Part B

One Threshold Floods the River

  • From Tuesday: flow → gage height → depth h above the river
  • Flooded = every cell with HAND ≤ h: Con("HAND" <= h, 1)
  • A different h for each return period: one iterator, as in Lab 6
CE 414 · Week 8 — Flood Mapping, Part B

Bathtub and HAND, Same Depth

  • Bathtub: drowns the lowland by the lake, never climbs the river
  • HAND: follows the river to the top of the study area
  • At the 1% level: bathtub 15.1 km², HAND 1.57 km²
CE 414 · Week 8 — Flood Mapping, Part B

How Good Is It?

  • Hit rate: of FEMA's floodplain, how much did we flood?
  • False-alarm ratio: of our flood, how much is FEMA dry?
  • CSI = hits ÷ (hits + misses + false alarms)
  • Lab 7 at the 1% flow: hit rate 0.548, false alarms 0.425, CSI 0.39
CE 414 · Week 8 — Flood Mapping, Part B

Where HAND Breaks

  • Levees and confined channels: HAND floods ground the river cannot reach
  • Split flow: water leaving one river for another path is invisible to D8
  • Lidar can't see under water: the channel bottom sits about 0.5 m above FEMA's streambed
  • No bridges, no roughness, no flow: terrain only
CE 414 · Week 8 — Flood Mapping, Part B

Part 3 — Lab 7, Flood Mapping with HAND

CE 414 · Week 8 — Flood Mapping, Part B

Lab 7 at a Glance

  • The reach: the Provo River through Provo, a 5 m lidar DEM, prepared for you
  • The model: Lab 5's chain + Flow Distance → HAND → one iterator over the stage table
  • The answer: flooded area and buildings for each FEMA flow
  • The check: your 1% flood against FEMA's floodplain

Lab 7 — Flood Mapping with HAND

CE 414 · Week 8 — Flood Mapping, Part B

Your Own Flow

Your flow = 900 + 12 × (last two digits of your BYU ID) ft³/s

  • BYU ID 123456789 → 89 → 900 + 12 × 89 = 1,968 ft³/s
  • The nine-digit number on your BYU ID card, not your NetID
  • Every personal flow is inside the rating: no extrapolation
CE 414 · Week 8 — Flood Mapping, Part B

Final Thoughts

Quiz: Height Above What? Five questions on HAND, stream definitions, thresholds and scoring a flood map. Scan the code, or open the link under it.

  • Not graded, nothing recorded: a quick check that today's material made sense
  • The stream-definition question comes back in Lab 7

Before next class

  • Midterm 1 closes tonight, 9:00 pm (late fee from 2:00 pm)
  • Lab 7 — Flood Mapping with HAND — due Saturday 11:59 pm
  • Next week: interpolation, and Lab 8
  • Office hours: calendly.com/dan-ames/office-hours

center

byu-hydroinformatics.github.io/ce414-gis-applications/quizzes/hand/

CE 414 · Week 8 — Flood Mapping, Part B

Thursday of Week 8. Tuesday ended on the bathtub's failure on a river and FEMA's expensive fix. Today: a terrain-only model that floods a whole river with one number, built from Lab 5's own chain plus one tool, and Lab 7, which does it on the Provo River and checks the answer against FEMA's new map.

stamp:begin

stamp:end

The two cells make the point: A is far higher above sea level than B, yet both sit just above their own river. On a bathtub map B floods first; on a HAND map they flood together at the same depth. Diagram drawn for this deck, not to scale.

The Lab 7 package's HAND raster (697,608 cells). White cells do not drain to the mapped Provo River inside the study area, so they have no HAND; that is correct, not a bug, and students will see it. Elevation range from the filled DEM. Numbers: tools/week08_flood_numbers.json.

Flow Distance (Spatial Analyst) with Vertical distance and D8 is HAND; checked in ArcGIS Pro 3.7.1's arcpy for the Lab 7 study (tools/lab07/PLAN.md). Two traps the study measured: running on the unfilled DEM leaves thousands of negative HAND cells, and defining "stream" as every cell above an accumulation threshold, with no river corridor, makes every gully a river (next slide).

Both panels at the Lab 7 1% depth, h = 1.527 m, on the package's filled DEM: left, HAND measured to every cell above the 2,000-cell accumulation threshold; right, only stream cells within 30 m of the mapped Provo River (the lab's model). In a city the threshold also makes streams of gutters and ditches. Lab 7's Step 7 varies the threshold for this reason. Figure and areas: tools/week08_flood_figures.py; 1.57 km² is the lab page's check value (1.5673).

The stage table in Lab 7 does the flow-to-h step for FEMA's 10%, 4%, 2% and 1% flows; students verify one row by hand from the rating. Raster to Polygon then gives an area and a polygon to intersect with buildings.

Same figure as Tuesday, now read from the right: HAND's water surface follows the river up to the mouth of Provo Canyon, where the bathtub never reaches.

Official values: the Lab 7 page's Step 6 check (tools/lab07/package_checks.json, polygon overlay inside Comparison_Area). The map's colors come from a raster tally of the same comparison. The feasibility study found CSI 0.39 to 0.40 for any h from 1.0 to 1.75 m: the agreement is limited by the terrain method, not by the hydrology.

The study found HAND flooding beside the confined upper reach and missing FEMA's overflow zone that leaves the river southward below the gage; the lidar channel sits about 0.47 m above FEMA's bed (Section T on the figure shows it). HAND's strength is scale: NOAA's Office of Water Prediction maps floods for the National Water Model with HAND: https://github.com/NOAA-OWP/inundation-mapping (checked October 9, 2026).

One-week lab during Midterm 1 week, so the data come prepared: DEM, river line, buildings, FEMA floodplain and the stage table are in the package. Two models: one builds HAND, one loops Iterate Field Values over the stage table (an iterator reruns every tool in its model). Check values on the page: river 3,191 cells, HAND 697,608 cells; floods from 1.29 km² and 319 buildings (10-yr) to 1.57 km² and 413 buildings (100-yr).

Range 900 to 2,088 ft³/s, all below the rating's top row of 2,150 ft³/s. The grader looks up each student's h, area and building count (ce414-private/grading-oracles/lab07_personal_lookup.csv).

Four minutes, in pairs. If the room has no signal, put the URL on the board.

Deck written October 9, 2026. Figures: tools/week08_flood_figures.py and three drawn diagrams; numbers from the Lab 7 package (tools/lab07/package_checks.json).
